Prepainted PE PVDF Ppgi Steel Coils Color Coated Galvanized Cold Rolled

Name: Prepainted PE PVDF Ppgi Steel Coils Color Coated Galvanized Cold Rolled
Brand: Yinghang
Price: 1 USD

Buy cheap Prepainted PE PVDF Ppgi Steel Coils Color Coated Galvanized Cold Rolled product

Brand Name : Yinghang

Model Number : PPGI06

Certification : SGS ISO

Place of Origin : China

MOQ : 25 tons per size

Price : Price Negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 1000000 tons per year

Delivery Time : 15-20 work days

Packaging Details : According To Customers' Requirement

Technic : cold rolled

Type : Prepainted Galvanized Steel Coil

Kayword : Color Coated Galvanized Steel Coil

Surface : Anti-finger print or no Anti-finger

Yield Strength : G300-G550

Paint Type : PE, SMP, HDP, PVDF

Width : 600-1250mm

Surface Production : PE,PVDF,SMP,HDP,ETC

Coating Type : PE, SMP, HDP, PVDF

Keyword : Color coated coil

Zinc Coating : 30-275g/m2

Application : Roofing, Wall, Sandwich Panel, Corrugated Sheet, etc.

Surface Treatment : Coated, Embossed, Printed

Coil Weight : 3-8 tons per coil

Product Thickness : 0.12-2.0mm

Contact Now

Product Introduction:

PPGI & PPGL (prepainted galvanized steel & prepainted galvalume steel) also known as pre-coated steel or color coated steel coil, It is a product made of hot-dip galvanized steel sheet, hot-dip galvalume steel sheet, electro galvanized steel sheet, etc. After surface pretreatment, one or several layers of organic coating are applied on the surface, and then baked and solidified.

The color coated steel coil is light in weight, beautiful in appearance, and has good anti-corrosion performance, and can be directly processed. The color is generally divided into gray, sea blue, brick red, etc. It is mainly used in advertising, construction, decoration, home appliances, electrical appliances, Furniture industry and transportation industry.

The coatings used for color coated steel coils are based on the environment in which the resin is selected, such as polyester silicon modified polyester, polyvinyl chloride plastisol, polyvinylidene chloride, and the like.

Product		Prepainted Galvanized Steel Coil ( PPGI )
Brand		Yinghang
Thickness		0.13mm—1.5mm
Width		600mm/914mm/1000mm/1200mm/1219mm/1250mm
Coil Weight		3-6 MT
Zinc coating		40g — 200g/sqm
Coil ID		508/610mm
Painting		Top painting: 15~25μm Back painting: 5~7μm
Tolerance		Thickness: +/-0.02mm Width:+/-2mm
Color		Ral colors / By samples / Normal Blue / White / Red
Capacity		30000 MT/month
Technique		Cold rolled—hot dipped galvanizing—color coated
Base material		Hot dipped galvalume steel sheet
Quality		SGS / ISO9001-2008
Package		waterproof paper, galvanized steel covered and steel strip packed
Market	Africa / Mid East / Southeast Asia / Uzbekistan / Russia

Coating Type of PPGI & PPGL

Polyester (PE)

Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.

Silicon modified polyester(SMP)

Good abrasion resistance and heat resistance, as well as good external durability and chalking resistance, gloss retention, general flexibility, and medium cost.

High Durability Polyester(HDP)

Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.

Polyvinylidene Fluoride(PVDF)

Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and high cost.

Polyurethane (PU)

Polyurethane coating has the characteristics of high wear resistance, high corrosion resistance and high damage resistance. Under normal circumstances, the shelf life is more than 20 years. It is mainly used for buildings with severe environmental corrosion.

Prepainted PE PVDF Ppgi Steel Coils Color Coated Galvanized Cold Rolled

Main Features of PPGI & PPGL

Good durability and long life compared with galvanized steel.

Good heat resistance, less discoloration at high temperature than galvanized steel.

Good thermal reflectivity.

Processability and spraying performance similar to galvanized steel.

Good welding performance.

Good performance-price ratio, durable performance and extremely competitive price.
